5.12kw Eastman Rack Lithium Battery-ES5.12V-100LP

🔋 Eastman Rack Lithium Battery ES5.12V-100LP (5.12kW)

The Eastman ES5.12V-100LP is a high-capacity Lithium Iron Phosphate (LiFePO₄) battery designed for reliable energy storage ⚡. With a 5.12kWh capacity and a 51.2V nominal voltage, it’s perfect for solar energy systems, UPS, telecommunications, and more.

📌 Key Specifications:

✅ 🔋 Nominal Energy: 5.12 kWh
✅ ⚡ Nominal Voltage: 51.2V
✅ 🔌 Charge Voltage: 58.4V
✅ ⚠️ Discharge Cut-off Voltage: 42V
✅ ⚙️ Standard Charging Current: 20A
✅ 🔋 Max. Continuous Charging Current: 100A
✅ ⚡ Max. Continuous Discharging Current: 100A
✅ 🔄 Cycle Life: Over 6000 cycles at 80% Depth of Discharge (DOD)
✅ 📡 Communication Mode: RS485/CAN
✅ 🌡️ Operating Temperature:

• Charging: 0°C to 60°C
• Discharging: -10°C to 65°C
  ✅ 📏 Dimensions (LxWxH): 520 x 495 x 175 mm
  ✅ ⚖️ Weight: ~43 kg

🔥 Top Features:

🔹 🛠️ Standardized Design: 3U rack-mounted case for easy installation.
🔹 🔋 Expandable Capacity: Supports parallel connection for higher energy needs.
🔹 🧠 Smart Battery Management System (BMS): Real-time monitoring & protection (overcharge, over-discharge, over-current, temperature control).
🔹 ⚖️ Auto Balancing Function: Ensures equal voltage levels between battery cells for optimal performance.
🔹 🚨 Advanced Warning System: Provides alerts for potential safety risks.

⚡ Applications:

🌞 Solar Energy Systems – Stores and manages solar power efficiently.
📡 Telecommunications – Ensures uninterrupted power for telecom towers.
🔋 Uninterruptible Power Supply (UPS) – Acts as a backup power source.
💡 Emergency Lighting – Keeps lights on during power outages.

💯 The Eastman ES5.12V-100LP is a versatile, safe, and long-lasting battery for modern energy storage needs. Perfect for solar systems, UPS, telecom, and emergency backup! 🚀🔋
