28kva 3ph Premier Silent Diesel Generator With ATS Heavy Duty

🔋 28kVA 3-Phase Premier Silent Diesel Generator With ATS (Heavy Duty) ⚡

🔹 Overview

The 28kVA 3-Phase Premier Silent Diesel Generator is a powerful and reliable backup solution designed for industrial, commercial, and residential applications. 🏭🏢🏠 With its heavy-duty build and low-noise silent enclosure 🔇, it ensures uninterrupted power in critical situations. The Automatic Transfer Switch (ATS) 🔄 seamlessly switches between mains and generator power, ensuring continuous operation during power failures.

⚙️ Technical Specifications

🛠️ Engine

• Engine Type: 4-Stroke, Water-Cooled Diesel Engine 🌡️
• Fuel System: Direct Injection ⛽
• Cooling System: Water-Cooled with Radiator 💦
• Start System: Electric Start with Battery 🔋
• Fuel Tank Capacity: Typically 60-80 Liters 🛢️
• Fuel Consumption: Approx. 5-6 L/hr at 75% Load
• Lubrication System: Forced Lubrication 🛠️

⚡ Alternator

• Type: Brushless, Self-Exciting, Synchronous Alternator ⚙️
• Voltage Output: 400/230V (Adjustable) 🔌
• Phase: 3-Phase ⚡⚡⚡
• Frequency: 50Hz or 60Hz (Model Dependent)
• Power Factor: 0.8
• Insulation Class: H-Class 🔥

📊 Control Panel

• Display: Digital Control Panel with LED/LCD Display 💻
• Functions: Voltage, Current, Frequency, Running Hours, Oil Pressure, Temperature, Battery Voltage, Fault Indicators 🚨
• Protections: Low Oil Pressure, High Temperature, Overload, Overvoltage, Short Circuit ⚠️

🔇 Silent Enclosure

• Enclosure Type: Weather-Resistant, Powder-Coated Silent Canopy ☔
• Noise Level: ≤ 70dB at 7 Meters 🔕
• Ventilation System: Optimized Airflow for Heat Dissipation

🔄 Automatic Transfer Switch (ATS)

• Functionality: Auto Start/Stop Based on Mains Power Availability 🔄
• Response Time: Instant Switching (<10 Seconds) ⚡
• Monitoring: Continuously Monitors Mains Voltage for Power Loss

📏 Physical Dimensions & Weight

• Weight: Approximately 800-1000kg ⚖️
• Dimensions: Approx. 2000mm x 900mm x 1300mm 📐

🏢 Applications

The 28kVA Premier Silent Diesel Generator is ideal for various applications, including:

• 🏭 Industrial Use: Factories, warehouses, and manufacturing plants requiring backup or prime power.
• 🏬 Commercial Establishments: Retail stores, offices, restaurants, hotels, and supermarkets.
• 🏠 Residential Power Backup: Large homes, apartments, and gated communities.
• 🚧 Construction Sites: Providing power for tools, lighting, and site equipment.
• 🏥 Healthcare Facilities: Hospitals, clinics, and labs requiring uninterrupted power.
• 💻 Data Centers & IT Infrastructure: Ensures continuous operations in case of power failure.

🛠️ Maintenance Guidelines

To ensure optimal performance and longevity, regular maintenance is required:

📅 Daily Checks

✅ Inspect fuel level and refill as needed.
✅ Check oil and coolant levels.
✅ Look for any leaks (fuel, oil, or coolant).
✅ Ensure the control panel and indicators function properly.

📆 Weekly Maintenance

🔹 Run the generator under load for at least 30 minutes to prevent wet stacking.
🔹 Check battery voltage and ATS functionality.
🔹 Clean the air intake and exhaust vents.

🗓️ Monthly Maintenance

🔧 Inspect air filter and clean/replace if necessary.
🔧 Test the ATS switch operation.
🔧 Check electrical connections and tighten if needed.

📅 Quarterly & Annual Maintenance

🔄 Change engine oil and oil filter as per manufacturer’s guidelines.
🔄 Replace fuel filters and inspect fuel lines.
🔄 Flush and replace coolant as needed.
🔄 Conduct a full system load test to ensure proper operation.
🔄 Inspect and clean the alternator and wiring connections.

The 28kVA 3-Phase Premier Silent Diesel Generator is a high-performance, heavy-duty power solution 💪⚡, perfect for industrial, commercial, and residential needs. With its low-noise operation 🔇, automatic switching system 🔄, and durable design, it guarantees uninterrupted power supply. Regular maintenance ensures long service life and efficiency. 🚀
