250L Solar Water Heater Non Pressurized Seven SS

Solar & Renewable Energy

250L Solar Water Heater Non Pressurized Seven SS

Name: 250L Solar Water Heater Non Pressurized Seven SS
Brand: Ruevan
Price: 77995.00 KES
Availability: InStock

KSh77,995.00 ~~KSh101,899.00~~

Product details

⚙️ Main Specifications – 250L Solar Water Heater Non-Pressurized Seven SS

✅ Capacity: 250 Liters 💧
✅ System Type: Non-Pressurized, Thermosiphon ♨️
✅ Collector Type: Vacuum Tube Collector 🌞
✅ Number of Tubes: 20–30 tubes 🔵
✅ Tube Material: Borosilicate Glass with Selective Coating 🔬
✅ Tube Size: ~58mm diameter, 1800mm length 📏
✅ Absorption Efficiency: ~92% ⚡
✅ Tank Material: Stainless Steel (SS 304/316) 🛢️
✅ Tank Insulation: Polyurethane Foam (PUF) (~50mm thick) 🏗️
✅ Frame Material: Stainless Steel or Aluminum Alloy 🔩
✅ Operating Temperature: 50°C - 95°C 🌡️
✅ Heat Retention: ~72 hours ⏳
✅ Mounting Angle: 20°-45° (depends on location) 📐
✅ Water Inlet Pressure: Gravity-fed (0 bar) 🚰
✅ Lifespan: 15+ years ⏲️
✅ Warranty: 5-10 years 🛠️

🌞 250L Solar Water Heater Non-Pressurized Seven SS

🔹 Detailed Description

The 250L Solar Water Heater Non-Pressurized Seven SS is an energy-efficient, eco-friendly solution for heating water using solar energy. It operates on the thermosiphon principle (♨️ natural convection) without requiring pumps or electricity. The system includes a stainless steel (SS) storage tank and high-efficiency vacuum tube collectors that capture solar energy to heat water.

Since it’s non-pressurized (💧 gravity-fed), it works best in locations where water is supplied from an overhead tank. The stainless steel build ensures durability and corrosion resistance, making it a long-lasting investment.

⚙️ Technical Specifications

📌 Feature	🔍 Specification
🔹 Capacity	250 Liters
🔹 System Type	Non-Pressurized, Thermosiphon
🔹 Collector Type	Vacuum Tube Collector (Glass Tubes)
🔹 Number of Tubes	20–30 tubes (depends on model)
🔹 Tube Material	Borosilicate Glass with Selective Coating
🔹 Tube Size	~58mm diameter, 1800mm length
🔹 Absorption Efficiency	~92%
🔹 Tank Material	Stainless Steel (SS 304/316)
🔹 Tank Insulation	Polyurethane Foam (PUF) (~50mm thick)
🔹 Frame Material	Stainless Steel or Aluminum Alloy
🔹 Operating Temperature	50°C - 95°C
🔹 Heat Retention	~72 hours
🔹 Mounting Angle	Typically 20°-45° (depends on latitude)
🔹 Water Inlet Pressure	Gravity-fed (0 bar)
🔹 Lifespan	15+ years with proper maintenance
🔹 Warranty	Typically 5-10 years

🏡 Applications

The 250L Solar Water Heater Non-Pressurized Seven SS is suitable for:

✅ 🏠 Residential Use – Provides hot water for families (4-6 people) for bathing, washing, and cooking.
✅ 🏨 Hotels & Lodges – Perfect for small guesthouses or lodges using low-pressure water supply.
✅ 🏫 Schools & Hostels – Supplies hot water for large groups efficiently.
✅ 🏥 Hospitals & Clinics – Helps with sterilization and hygiene needs.
✅ 🌿 Rural & Off-Grid Areas – Works great in locations with limited electricity, running solely on solar power.

🛠️ Maintenance & Care

Proper maintenance ensures optimal efficiency and extends the lifespan of your solar water heater (⚡♨️).

🔄 Regular Maintenance Tasks

🔹 Clean the Vacuum Tubes – Remove dust and debris every 3-6 months for maximum sunlight absorption. ☀️
🔹 Check Water Inlet & Outlet – Ensure there are no blockages or leaks. 🚰
🔹 Inspect the Storage Tank – Look for any corrosion or damage in the stainless steel tank. 🏗️
🔹 Flush the System – Remove sediment or mineral buildup every 6-12 months. 💦
🔹 Check for Leaks – Inspect all joints, seals, and connections. Replace rubber gaskets if needed. 🔧
🔹 Monitor Insulation – Ensure polyurethane foam (PUF) insulation is intact to prevent heat loss. ❄️

🌦️ Seasonal Maintenance

❄️ Winter Care – Protect against freezing by insulating pipes or using an anti-freeze solution.
🔥 Summer Optimization – If overheating occurs, install a temperature relief valve.

By following these maintenance tips, your 250L Solar Water Heater Non-Pressurized Seven SS will keep delivering hot water efficiently for years to come! 🚿♻️💧
