9.5kva 1phase Pyramid Silent Diesel Generator With ATS

🔋 Power Output: 9.0 kVA (Rated) | 9.5 kVA (Max) for reliable electricity supply.

⚡ Voltage & Frequency: 240V | 50 Hz, ensuring compatibility with standard appliances.

🛞 Engine Type: Vertical, single-cylinder, 4-stroke, air-cooled diesel engine (Model KD186FE).

🔑 Starting System: Electric starter 🚀 for quick and hassle-free ignition.

⛽ Fuel Tank Capacity: 14.5 liters (~8 hours runtime) for extended use without frequent refueling.

🔊 Noise Level: 70-72 dB @ 7 meters (Super silent 🤫), making it ideal for noise-sensitive environments.

🔌 Pyramid 9.5kVA 1-Phase Silent Diesel Generator with ATS 🔋

The Pyramid 9.5kVA Single-Phase Silent Diesel Generator with Automatic Transfer Switch (ATS) ⚡ is designed to provide reliable backup power for homes 🏡, businesses 🏢, and various other applications.

🛠️ Technical Specifications:

• 🔋 Power Output: 9.0 kVA (Rated) | 9.5 kVA (Max)
• ⚡ Voltage: 240V
• 🔄 Frequency: 50 Hz
• 🛞 Engine Type: Vertical, single-cylinder, 4-stroke, air-cooled diesel engine (Model KD186FE)
• 📏 Engine Displacement: 406 cm³ (Bore x Stroke: 86×70 mm)
• 🔥 Compression Ratio: 19:1
• ⚙️ Rated Power: 5.7 kW @ 3000 rpm
• 🔑 Starting System: Electric starter 🚀
• ⛽ Fuel Tank Capacity: 14.5 liters (~8 hours runtime)
• 🔊 Noise Level: 70-72 dB @ 7 meters (Super silent 🤫)
• 🔄 ATS Compatibility: ✅ (Seamless switch during power outages)

📏 Weight & Dimensions:

• ⚖️ Net Weight: 155 kg
• 📐 Dimensions (L×W×H): 950×540×750 mm

🔧 Maintenance Guidelines:

To keep your generator running smoothly, follow these regular maintenance tips:

• 🛢️ Oil Change: Every 100 hours ⏳
• 🌬️ Air Filter Cleaning: Every 50 hours 🔄
• 🛠️ Fuel Line Inspection: Check for leaks and replace worn parts 🔍
• 🔄 Routine Operation: Run at least once a month to keep it in top shape ✅

💡 Applications:

This versatile generator can be used for:
🏡 Residential Backup: Powering appliances, lights, and essential devices during outages.
🏢 Commercial Use: Keeping businesses, shops, and offices running without interruptions.
🏗️ Construction Sites: Providing electricity for tools and machinery in remote areas.
🚜 Agriculture: Running irrigation systems and farming equipment.

⚡ The Pyramid 9.5kVA Silent Diesel Generator with ATS ensures reliable, efficient, and quiet power backup for all your needs! ⚡
