Pellet Machine 200kgs/hr 5hp Motor PT1500

🔋 Powerful 5HP Motor – Delivers consistent torque and energy-efficient performance for long operation hours.

🏭 High Output Capacity – Produces up to 200 kg of pellets per hour, ideal for small-scale commercial use or farm applications.

⚙️ Flat Die Design – Simplifies pelletizing, ensures even compression, and allows for easy die replacement and maintenance.

🎯 Customizable Pellet Size – Adjustable die options (2mm–8mm) to suit various feed or biomass needs.

♻️ Multi-Material Compatibility – Processes sawdust, straw, husks, feed ingredients, and organic waste into uniform pellets.

🧰 Compact & Mobile – Sturdy yet portable build, easy to install and operate with minimal space requirements.

🔧 Pellet Machine 200kgs/hr 5HP Motor PT1500

The PT1500 Pellet Machine is a robust and efficient biomass pelletizing solution designed for small to medium-scale production. Ideal for farms, feed processing units, and biomass fuel producers, it delivers high-quality pellets from raw materials like sawdust, straw, rice husks, and animal feed ingredients. 🌾🔥

📊 Technical Specifications:

• Model: PT1500

• Production Capacity: Up to 200 kg/hr 🏭

• Motor Power: 5 HP (3.7 kW) ⚙️

• Voltage: 220V / 380V (customizable) ⚡

• Pellet Diameter: 2mm to 8mm (custom dies available) 🎯

• Die Type: Flat die 🥚

• Feeding Type: Gravity feed ⬇️

• Weight: Approx. 120–150 kg ⚖️

• Dimensions: 1000mm x 450mm x 850mm 📏

• Material Compatibility: Biomass (wood, straw, husks), animal feed, organic waste ♻️

🛠️ Applications:

• Animal Feed Production: Suitable for poultry, cattle, pig, and rabbit feed pellets 🐓🐄🐖

• Biomass Fuel Production: Converts agricultural residues into renewable heating fuel 🌿🔥

• Fertilizer Pelletizing: Organic fertilizers from compost or manure 🌱

• Small Farm Use: Helps farmers reduce waste and create value-added products 🚜

🧼 Maintenance Tips:

• 🔩 Regular Cleaning: Clean the die and roller after each use to avoid material build-up.

• 🧯 Lubrication: Grease the bearings and rotating parts every 40-60 hours of operation.

• 🔍 Inspection: Check for wear on the die and roller weekly. Replace if holes are worn out or roller is flat.

• ⚠️ Belt Tension: Ensure V-belts are tight and not fraying for smooth power transmission.

• 🛑 Shutdown Procedure: Turn off the machine and disconnect power before any maintenance.

• 🗄️ Storage: Keep in a dry, covered place to prevent rust and corrosion.

This compact and powerful pellet machine is an excellent choice for those looking to turn raw material into profitable, eco-friendly pellets. Whether for feeding animals or fueling homes, the PT1500 gets the job done efficiently. 💪🌍
